Headsets

- Forged steel cups with caged 5/32" ball bearings - TH-857 features a alloy top cover - TH Series: External Cup, traditional - S.H.I.S.: EC34/28.6|EC34/30 - Stack: 14.9mm/11mm - Color: Black - Weight: 126g

Zipp's Stem Top Cap and Bolt are designed to work specifically with Zipp stems. The eight-gram aluminum cap and nine-gram-bolt are the same as those used on bikes built for Zipp-sponsored professional teams. The bolt has a T25 Torx head for ease of adjustment and so you need only one tool for your Zipp cockpit.

A new headset gives you a new lease on life. This is the upper part of an integrated headset for a 44mm headtube. - Lower part of the headset sold separately

- Microspacers ensure the correct fitment of integrated headsets - Use between the top cover and the compression ring to ensure the top cover does not contact the headtube - Sold in bags of 10

- No. series headsets offer excellent performance and value - No. 8b: 36x45 degree Cane Creek Integrated, or No. 10: Zero Stack shallow available for 1-1/8" applications - No. 10 S.H.I.S.: ZS44/28.6|ZS44/30 - No. 8B S.H.I.S.: IS42/28.6|IS42/30 - Stack: 5.2mm/3.7mm (No. 10), 8mm/1mm (No. 8B) - Color: Black - Weight: 93g (No. 10), 74g (No. 8B)

- Bearing Type: Cartridge - Weight: 86 g - Crown Race: 40 - S.H.I.S Lower: IS52 - S.H.I.S Upper: IS42 - S.H.I.S. Stem Clamp Diameter: 28.6 Threadless

- Carbon fiber top cover - Upper: Campagnolo angular contact bearings (black seal) - 1-1/8-inch, 45 degrees/ 45 degrees ACB upper - 1.5-inch, 36 degrees/ 45 degrees ACB lower - For tapered 46mm/56mm OD headtube - For 1-1/8-inch to 1.5-inch tapered fork

- Weight: 160g - Crown Race: 30 - S.H.I.S. Lower: EC34 - S.H.I.S. Upper: EC34 - S.H.I.S. Stem Clamp Diameter: 28.6 Threadless

A solid choice for 1-1/8in frames, the Orbit Equipe features a sturdy steel lower cup for maximum durability. The top cup is forged alloy, with an alloy top cover. Inside are two low maintenance, easy-to-replace sealed cartridge angular contact bearings. - Bearing Type: Cartridge - Weight: 117g - Crown Race: 30 - S.H.I.S. Lower: EC34 - S.H.I.S. Upper: EC34 - S.H.I.S. Stem Clamp Diameter: 28.6 Threadless

Cane Creek compatible integrated style bearings fit directly into headtube. - 36-degree inner chamfer and 45-degree outer chamfer - Crown Race: 30 - S.H.I.S. Lower: IS41 - S.H.I.S. Upper: IS41 - S.H.I.S. Stem Clamp Diameter: 28.6 Threadless

- Pig DH-Pro feature angular contact sealed upper bearing and an industrial cartridge sealed bearing with an alloy upper cup and CrMo lower cup - Pig feature oversized 1/4" lower ball bearings, 5/32" upper bearings - Big Fat Pig feature super oversized caged ball bearings - Pig: External Cup, traditional - Pig S.H.I.S.: EC34/28.6|EC34/30 - Big Fat Pig S.H.I.S.: EC49/38.1|EC49/40 - Pig DH Pro S.H.I.S.: EC34/28.6|EC34/30 - Stack: 15.4mm/13.6mm (Pig), 17mm/11.7mm (Big Fat Pig), 15.5mm/16mm (Pig DH Pro) - Color: Black - Weight: 193g (Pig), 345g (Big Fat Pig), 198g (Pgi DH Pro)

Cane Creek's 10 Series has light, tough, and beautiful machined 6061 T6-aluminum cups, Cane Creek's corrosion-resistant black-oxide angular-contact bearings and quality seals throughout to keep the grease in and the dirt out. • Technical Description: EC34/28.6/H16/K|EC34/30 /H12/K • Top Type: EC - External Cup • Top Head Tube Inside Dia.: 33.95mm • Stem Clamp Dia.: 28.6mm • Top Stack Height: 16mm • Top Bearing Type: Black Oxide • Bottom Type: EC - External Cup • Bottom Head Tube Inside Dia.: 33.95mm • Crown Race Seat Dia.: 30.015mm • Crown Race Type: Polymer • Bottom Stack Height: 12mm • Bottom Bearing Type: Black Oxide • Material: 6061 aluminum • Weight: 88.29g

Cane Creek's 10 Series has light, tough, and beautiful machined 6061 T6-aluminum cups, Cane Creek's corrosion-resistant black-oxide angular-contact bearings and quality seals throughout to keep the grease in and the dirt out. • Technical Description: EC34/28.6/H16/K • Top Type: EC - External Cup • Top Head Tube Inside Dia.: 33.95mm • Stem Clamp Dia.: 28.6mm • Top Stack Height: 16mm • Top Bearing Type: Black Oxide • Material: 6061 aluminum • Weight: 48.17g

Cane Creek's 10 Series has light, tough, and beautiful machined 6061 T6-aluminum cups, Cane Creek's corrosion-resistant black-oxide angular-contact bearings and quality seals throughout to keep the grease in and the dirt out. • Technical Description: EC49/40/H12/K • Bottom Type: EC - External Cup • Bottom Head Tube Inside Dia.: 49.61mm • Crown Race Seat Dia.: 39.79mm • Crown Race Type: Polymer • Bottom Stack Height: 12mm • Bottom Bearing Type: Black Oxide • Material: 6061 aluminum • Weight: 76.57g

Cane Creek's 10 Series has light, tough, and beautiful machined 6061 T6-aluminum cups, Cane Creek's corrosion-resistant black-oxide angular-contact bearings and quality seals throughout to keep the grease in and the dirt out. • Technical Description: IS52/40/H1 • Bottom Type: IS - Integrated • Bottom Head Tube Inside Dia.: 52.1mm • Crown Race Seat Dia.: 39.79mm • Crown Race Type: Polymer • Bottom Stack Height: 1mm • Bottom Bearing Type: Black Oxide • Material: N/A • Weight: 35.35g

Super-smooth steering, quality materials, cutting-edge design and serious durability are all hallmarks of Cane Creek headsets. The 10 Series has light, tough and beautiful machined 6061 T6-aluminum cups, Cane Creek's corrosion-resistant black-oxide angular-contact bearings and quality seals throughout to keep the grease in and the dirt out.

• Replacement semi-cartridge bearings for Cane Creek 10-Series headsets • Bearing I.D. (mm): 30 mm • Bearing O.D. (mm): 41 mm • Bearing Type: Cartridge • Cartridge Bearing Angle: 36x45 • Thickness: 6.5 mm

Cane Creek's 10 Series has light, tough, and beautiful machined 6061 T6-aluminum cups, Cane Creek's corrosion-resistant black-oxide angular-contact bearings and quality seals throughout to keep the grease in and the dirt out. • Technical Description: ZS44/28.6/H8/K|ZS44/30/H4/K • Top Type: ZS - ZeroStack • Top Head Tube Inside Dia.: 44.00mm • Stem Clamp Dia.: 28.6mm • Top Stack Height: 8mm (Short), 15mm (Tall) • Top Bearing Type: Black Oxide • Material: 6061 aluminum • Weight: 62.79g

Super-smooth steering, quality materials, cutting-edge design and serious durability are all hallmarks of Cane Creek's 110 headsets. • Technical Description: EC34/30/H12/x • Bottom Type: EC - External Cup • Bottom Head Tube Inside Dia.: 33.95mm • Crown Race Seat Dia.: 30.015mm • Crown Race Type: Aluminum, Dual-Seal • Bottom Stack Height: 12mm • Bottom Bearing Type: Top-quality, sealed stainless steel bearings • Material: 7075 aluminum • Weight: 42.20g

Super-smooth steering, quality materials, cutting-edge design and serious durability are all hallmarks of Cane Creek's 110 Series headsets. • Technical Description: EC34/28.6/H16/x • Top Type: EC - External Cup • Top Head Tube Inside Dia.: 34mm • Stem Clamp Dia.: 28.6mm • Top Stack Height: 16mm • Top Bearing Type: Top-quality, sealed stainless steel bearings • Material: 7075 aluminum • Weight: 55.26g

Super-smooth steering, quality materials, cutting-edge design and serious durability are all hallmarks of Cane Creek's 110 headsets. • Technical Description: EC44/40/H12/x • Bottom Type: EC - External Cup • Bottom Head Tube Inside Dia.: 44.00mm • Crown Race Seat Dia.: 39.76mm • Crown Race Type: Aluminum, Dual-Seal • Bottom Stack Height: 12mm • Bottom Bearing Type: Top-quality, sealed stainless steel bearings • Material: 7075 aluminum • Weight: 61.02g

Super-smooth steering, quality materials, cutting-edge design and serious durability are all hallmarks of Cane Creek's 110 headsets. • Technical Description: EC49/30/H12/x • Bottom Type: EC - External Cup • Bottom Head Tube Inside Dia.: 49.61mm • Crown Race Seat Dia.: 30.015mm • Crown Race Type: Aluminum, Dual-Seal • Bottom Stack Height: 12mm • Bottom Bearing Type: Top-quality, sealed stainless steel bearings • Material: 7075 aluminum • Weight: 83.01g

Super-smooth steering, quality materials, cutting-edge design and serious durability are all hallmarks of Cane Creek's 110 headsets. • Technical Description: IS41/30/H1 • Bottom Type: IS - Integrated • Bottom Head Tube Inside Dia.: 41.1mm • Crown Race Seat Dia.: 30.015mm • Crown Race Type: Aluminum, Dual-Seal • Bottom Stack Height: 1mm • Bottom Bearing Type: Top-quality, sealed stainless steel bearings • Weight: 24.91g

Super-smooth steering, quality materials, cutting-edge design and serious durability are all hallmarks of Cane Creek's 110 headsets. And, the 110 comes with an amazing 110-year, no-questions-asked warranty! • Technical Description: IS41/28.6/H9/x • Top Type: IS - Integrated • Top Head Tube Inside Dia.: 41.1mm • Stem Clamp Dia.: 28.6mm • Top Stack Height: 9mm (Short), 15mm (Tall) • Top Bearing Type: Top-quality, sealed stainless steel bearings • Material: 7075 aluminum • Weight: 41.81g

Cane Creek's engineers were tasked with developing a no-compromise, best-in-class premium headset. With the introduction of their 110-Series, they did just that—choosing optimal materials, engineering the most effective internals and designing the best aesthetics available in a headset. - Technical Description: 110-Series IS41/28.6/H9 | IS52/40 - Top Type: IS - Integrated - Top Head Tube Inside Dia.: 41.1mm - Stem Clamp Dia.: 28.6mm - Top Stack Height: 9mm - Top Bearing Type: Top-quality, sealed stainless steel bearings - Bottom Type: IS - Integrated - Bottom Head Tube Inside Dia.: 52.1mm - Crown Race Seat Dia.: 39.79mm - Crown Race Type: Aluminum, Dual-Seal - Bottom Stack Height: 1mm - Bottom Bearing Type: Top-quality, sealed stainless steel bearings - Material: N/A - Weight: 79.48 grams

Super-smooth steering, quality materials, cutting-edge design and serious durability are all hallmarks of Cane Creek's 110 headsets. • Technical Description: IS42/30/H1 • Bottom Type: IS - Integrated • Bottom Head Tube Inside Dia.: 42.1mm • Crown Race Seat Dia.: 30.015mm • Crown Race Type: Aluminum, Dual-Seal • Bottom Stack Height: 1mm • Bottom Bearing Type: Top-quality, sealed stainless steel bearings • Weight: 41.91g

Super-smooth steering, quality materials, cutting-edge design and serious durability are all hallmarks of Cane Creek's 110 headsets. • Technical Description: IS42/28.6/H9/x • Top Type: IS- Integrated • Top Head Tube Inside Dia.: 42.1mm • Stem Clamp Dia.: 28.6mm • Top Stack Height: 9mm (Short), 15mm (Tall) • Top Bearing Type: Top-quality, sealed stainless steel bearings • Material: 7075 T Aluminum • Weight: 41.81g

This is the Bottom External Cup for the Cane Creek 110 Series headset. Please contact us if you have any questions about which parts are correct for your headset.

Super-smooth steering, quality materials, cutting-edge design and serious durability are all hallmarks of Cane Creek headsets. The 110 Series has light, tough, and beautiful machined 7075 T6-aluminum cups that are contoured and relieved for even more gram shaving and strength. You also get top-quality split-lip sealed stainless-steel bearings, a carbon-friendly captured compression ring and a dual-sealed crown race and complete upper bearing seal to keep the grease in and the dirt out. What's more, the seals are low-friction to improve steering performance and there are no loose headset parts so maintenance is easy. The 110 comes with an amazing 110-year, no-questions-asked warranty too!

This is the Integrated Bottom Bearing for the Cane Creek 110 Series headset. Please contact us if you have any questions about which parts are correct for your headset.
